Emulations User guide
152
Barcode Even the standard version of your printer has the possibility of using
up to 22 different barcode types.
Barcode mode can be accessed within every emulation. The
user can decide whether barcode is activated permanently or
activated depending on the situation by means of an escape
sequence.
List of available barcodes
* These barcodes may be printed out horizontal and vertical, the unmarked only
horizontal.
The barcode types K, L, N, O may be expanded by using Add-On
Barcodes: Add-On 2 and Add-On 5.
The information to be printed is transmittted in a “bracket” (DC4)
A control sequence (Header) defines the parameters of the used
barcode once (e.g. type, ratio, etc.). If no header is defined, the in-
formation in the “bracket” will be printed in Code 2/5 Matrix.
Please note that within the Barcode environment the barcode
commands have priority in case of conflicts with the emula-
tion.
Additional information is provided in the Barcode Program-
mer’s Applcaton Manual on this CD-ROM.
Type Barcode Type Barcode
A* 2/5 Matrix (default) M* MSI /modified PLESSEY
B* 2/5 Industrial N UPC A (with HRI)
C* 2/5 Interleaved O* UPC A (without HRI)
D* Code 11 P* UPC E (with HRI)
E* BCD Matrix Q* UPC E (without HRI)
F* Code 39 R* Delta Distance (IBM)
G* Codabar S* Code 128
H* EAN 8 (with HRI) T* EAN 128
I* EAN 8 (without HRI) US-Postnet
K* EAN 13 (with HRI) KIX Barcode
L* EAN 13 (without HRI) Royal Mail Customer Barcode
