18 – Appendix
MIDI Control Change message
When this unit receives MIDI Control Change messages from an external device (such as a sequencer), it can control the
mixer parameters and effect parameters.
Mixer control change parameters
Select a channel group of 8 track/input channels beforehand.
The Bank Select message is used with the MIDI channel 14 to select a channel group.
Bank 0: track channels 1 to 8
•
Bank 1: track channels 9 to 16
•
Bank 2: track channels 17 to 24
•
Bank 3: inputs A to H
•
The following table shows the variable range of mixer parameter and mapping to the MIDI Control Change.
MIDI Channel
1 - 8 16
Track/Input Channel Stereo Master
Control Change
Number
Parameter Values
7 Internal Level 0 - 127 (0=–∞dB, 105=0dB, 127=+6dB) 0 - 127 (–∞ - 0dB)
10 Pan 1 - 64 - 127=L63 - C (center) - R63
—
11 DigitalTrim 0 - 48 (–42 - +6dB)
16 Low Freq
0 - 31=
32, 40, 50, 60, 70, 80, 90, 100, 125, 150, 175, 200, 225, 250, 300, 350, 400, 450, 500,
600, 700, 800, 850, 900, 950, 1.0k, 1.1k, 1.2k, 1.3k, 1.4k, 1.5k, 1.6k (Hz)
17 Low Gain 0 - 24=–12 - +12 (dB)
18 Mid Freq
0 - 63=
32, 40, 50, 60, 70, 80, 90, 100, 125, 150, 175, 200, 225, 250, 300, 350, 400, 450, 500,
600, 700, 800, 850, 900, 950, 1.0k, 1.1k, 1.2k, 1.3k, 1.4k, 1.5k, 1.6k, 1.7k, 1.8k, 1.9k,
2.0k, 2.2k, 2.4k, 2.6k, 2.8k, 3.0k, 3.2k, 3.4k, 3.6k, 3.8k, 4.0k, 4.5k, 5.0k, 5.5k, 6.0k, 6.5k,
7.0k, 7.5k, 8.0k, 9.0k, 10k, 11k, 12k, 13k, 14k, 15k, 16k, 17k, 18k (Hz)
19 Mid Gain 0 - 24=–12 - +12 (dB)
20 Mid Q 0 - 6=0.25, 0.5, 1, 2, 4, 8, 16
21 High Freq
32 - 63=
1.7k, 1.8k, 1.9k, 2.0k, 2.2k, 2.4k, 2.6k, 2.8k, 3.0k, 3.2k, 3.4k, 3.6k, 3.8k, 4.0k, 4.5k, 5.0k,
5.5k, 6.0k, 6.5k, 7.0k, 7.5k, 8.0k, 9.0k, 10k, 11k, 12k, 13k, 14k, 15k, 16k, 17k, 18k (Hz)
22 High Gain 0 - 24=–12 - +12 (dB)
23 EFFECT1 Level 0 - 127 (0=–∞dB, 127=0dB) EFFECT1 Level
24 EFFECT2 Level 0 - 127 (0=–∞dB, 127=0dB) EFFECT2 Level
80 EQ SW 0, 1=OFF, ON
81 EFFECT1 Position 0, 1, 2=OFF, PRE, POST
—
82 EFFECT2 Position 0, 1, 2=OFF, PRE, POST
