4 – Preparation
Inserting and removing SD cards
Inserting an SD card
Insert the SD card into the SD card slot on the rear panel
as shown in the illustration until it clicks into place.
NOTE
An SD card is installed in the SD card slot when the unit is
shipped from the factory. If you want to use this card to
record and play tracks, there is no need to reinstall it.
Removing the card
Push the loaded card in gently to eject it.
CAUTION
Always turn the power off (standby) before removing
•
an SD card.
If you remove or insert an SD card when the power is
on, recorded data may be lost and cannot be recovered.
SD and SDHC cards that are at least 512 MB in size can
•
be used.
A list of SD cards that have been confirmed to work
•
with this unit can be found on TASCAM website (http://
tascam.com/).
About write-protected SD cards
SD cards have write-protect (lock) switches.
When the protect switch is in the LOCK position, files
cannot be recorded or edited on the card. Slide the switch
away from the LOCK position if you want to record, erase
or otherwise change files on a card.
Powering the unit
As shown in the illustration, connect the included TASCAM
PS-1225L AC adapter to the DC IN 12V jack.
The bottom panel has a hook (cord holder) that can be
used to hold the AC adapter cord in place. When using it,
wrap the cord around this cord holder to prevent it from
being disconnected during use.
CAUTION
Use only the included TASCAM PS-1225L AC adapter
•
and power cord. Use of a different AC adapter could
cause malfunction, fire or electric shock.
Be sure to use the included TASCAM PS-1225L AC
•
adapter to supply power to this unit. Power cannot be
supplied to this unit via USB.
Unprotected Protected
AC outlet
DC plug
To Next Page
