18 – Appendix
MIDI Program Change message
When this unit receives MIDI Program Change messages,
it can call settings from the effect libraries.
The Bank Select message of MIDI Control Change is used
to select presets and users of the effect libraries.
Different MIDI Channels are applied for each item.
MIDI
Channel
Parameter Function Value
1 - 8*
Recalling the dynamic
effect type
Bank 0 (Type): 0 - 3
10
Calling from the send
effect library
Bank 0 (Preset): 0 - 6
Bank 1 (User): 0 - 9
11
Calling from the guitar
effect library
Bank 0 (Preset): 0 - 9
Bank 1 (User): 0 - 9
* The Bank Select message of MIDI Control Change is
used with the MIDI channel 14 to select a channel group
for the dynamic effect.
Bank 0: track channels 1 to 8
•
Bank 1: track channels 9 to 16
•
Bank 2: track channels 17 to 24
•
Bank 3: inputs A to H
•
The following tables show the preset libraries of each
effect.
Dynamic effects
Program
Change
Display Effect type
0
COMP CMP
1
NOISE SUPRESSOR NSP
2
DE-ESSER DSR
3
EXCITER EXC
CMP: Compressor
•
DSR: De-Esser
•
EXC: Exciter
•
NSP: Noise Suppressor
•
Preset libraries of the send effects
Program
Change
Display Effect type
0
HALL REV
1
ROOM REV
2
LIVE REV
3
STUDIO REV
4
PLATE REV
5
CHORUS CHO
6
STEREO DLY DLY
REV: Reverb
•
DLY: Delay
•
CHO: Chorus
•
Preset libraries of the guitar effects
Program
Change
Display Effect type
0
PRESET 01 AMP, CMP, DLY
1
PRESET 02 AMP, CHO
2
PRESET 03 AMP
3
PRESET 04 AMP, CMP, DLY
4
PRESET 05 AMP, FLG
5
PRESET 06 AMP, CMP
6
PRESET 07 AMP, CMP, CHO
7
PRESET 08 AMP, CMP, PHA
8
PRESET 09 AMP
9
PRESET 10 AMP, CMP, WAH
AMP: Amplifier
•
CMP: Compressor
•
FLG: Flanger
•
PHA: Phaser
•
CHO: Chorus
•
WAH: Wah
•
DLY: Delay
•
