Tascam Digital Portastudio DP-24 User Manual

TASCAM DP-24 97
17 – Specifications
Ratings
Recording media
SD card (512 MB to 2 GB)
SDHC card (4 GB to 32 GB)
File system
SD card (512 MB to 2 GB) : FAT16
SDHC card (4 GB to 32 GB) : FAT32
Input/output ratings
Analog audio input/output ratings
INPUT A to H jack
XLR type (Balanced)
•
Connector: XLR-3-31 (1 : GND, 2 : HOT, 3 : COLD)
Input impedance: 2.4 kΩ
Rated input level: –14 dBu
Maximum input level: +2 dBu
Standard jack type (Balanced)
•
Connector: 6.3 mm (1/4") TRS standard jack
Input impedance:
Above 22 kΩ
1 MΩ (INPUT H only, when LINE-GUITAR switch is
set to GUITAR)
Rated input level: +4 dBu
Maximum input level: +20 dBu
STEREO OUT jack
Connector: RCA pin jack
Rated output level: –10 dBV
Maximum output level: +6 dBV
Output impedance: 200 Ω
EFFECT SENDS jack
Connector: 6.3 mm (1/4") TS standard jack
Rated output level: –10 dBV
Maximum output level: +6 dBV
Output impedance: 200 Ω
MONITOR OUT jack
Connector: 6.3 mm (1/4") TRS standard jack
Rated output level: –2 dBu
Maximum output level: +14 dBu
Output impedance: 200 Ω
PHONES jack
Connector: 6.3 mm stereo jack
Maximum output level: 70 mW+70 mW or more
(THD+N 0.1% or less, 32 Ω load)
Control input/output ratings
MIDI input (MIDI IN)
Connector: 5-pin DIN
Format: Standard MIDI format
MIDI output (MIDI OUT)
Connector: 5-pin DIN
Format: Standard MIDI format
USB port
Connector: USB 4-pin mini-B type
Format: Mass Storage Class USB 2.0 HIGH SPEED
REMOTE jack
Connector: 2.5 mm TRS jack
Audio performance
Frequency response
INPUT (MIC/LINE) q STEREO OUT/EFFECT SENDS/
MONITOR OUT: 20 Hz to 20 kHz, +1 dB/–1 dB
Distortion
INPUT (MIC/LINE) q STEREO OUT/EFFECT SENDS/
MONITOR OUT: 0.01% or less
S/N ratio
INPUT (MIC/LINE) q STEREO OUT/EFFECT SENDS/
MONITOR OUT: 90 dB or more
Operating requirements
See the TASCAM website (http://www.tascam.com/) for
updated information about OS compatibility.
Windows
Pentium 300 MHz or faster
128 MB or more memory
USB port (USB 2.0 recommended)
Macintosh
Power PC, iMac, G3, G4 266 MHz or faster
64 MB or more memory
USB port (USB 2.0 recommended)
Recommended USB host controller
Intel chipset
Supported OS
Windows: Windows XP, Windows Vista, Windows 7
Macintosh: Mac OS X 10.2 or later

Tascam Digital Portastudio DP-24 Specifications

General

Tracks	24
Simultaneous Recording Tracks	8
Storage Media	SD/SDHC card
Digital Output	No
Inputs	8 XLR/TRS combo jacks
Phantom Power	Yes
Built-in Effects	Reverb, Chorus, Delay, EQ
Display	Color LCD
USB	USB 2.0
Weight	6.2 kg
Outputs	Stereo output, monitor output
Headphone Output	1/4" stereo
Resolution	24-bit/48 kHz
Power Supply	AC adapter
