2 - Quick Guide
Playback and mixing
In this section, we will play back the demo song on the
included SD card.
When this unit is purchased new, the SD card with the
demo song on it is already installed in the unit, but we
will start by explaining how to insert an SD card using the
procedures below.
Preparation
1. Insert the included SD card into the SD card slot
on the rear panel. Be careful not to forcibly insert
the card in the wrong direction. Doing so could
damage the SD card slot or the SD card.
2. Connect the supplied AC adapter (TASCAM PS-
1225L) to the DC IN 12V jack on the rear panel.
The bottom panel has a hook (cord holder) that can be
used to hold the AC adapter cord in place. When using
it, wrap the cord around this cord holder to prevent it
from being disconnected during use.
CAUTION
Never use any AC adapter or power cord other than the
supplied TASCAM PS-1225L AC adapter and AC adapter
power cord. Use of a different adapter could cause
malfunction, fire or electric shock.
3. Connect headphones to the PHONES jack on the
front panel.
4. Press and hold the STANDBY/ON button for a few
seconds on the rear panel to turn the power ON.
When the unit starts, the Home screen appears on
the display.
Start-up screen
Home screen
CAUTION
Do not remove or insert an SD card when the power
•
is ON. Always turn the power OFF (standby) before
removing or inserting an SD card.
AC outlet
Headphones
DC plug
