5.4 Vacuum unit & squeegee
5.4.2 Mounting of vacuum motor
• Position seals, noise absorbers and covers correctly.
Remarks
The sequence of the seals, noise absorbers and covers is described in
the spare parts list.
Picture 31: Vacuum motor details
• Connect vacuum motor wires to the connection block.
• Position the assembled vacuum motor into the chassis.
• Complete assembling according to chapter MOUNTING OF
FRESH WATER TANK ASSEMBLY.
