GTS Technical Manual
14. March 2014 Edition: V1.00/2014 5-30
Copyright © 2014, Diversey Care
05.72.25 mangetic valve & water outlet - filter - 30_45_V1.00.fm
5.5 Magnetic valve & water outlet
5.5.3 Removing of fresh water filter
Picture 44: Filter housing
• Open fresh water tank according to chapter REMOVING OF FRESH
WATER TANK ASSEMBLY.
Ensure that no water is in the fresh water system before you
disconnect the hoses.
Remarks
For a better access to the filter, remove the vacuum motor and pump.
• Remove the hose (30:06/116, 45:07/116) from the fast
connector on the filter (30:06/102, 45:07/102).
• Remove the two cable ties of the filter.
• Lift out the filter.
