GTS Technical Manual
14. March 2014 Edition: V1.00/2014 5-31
Copyright © 2014, Diversey Care
05.72.25 mangetic valve & water outlet - filter - 30_45_V1.00.fm
5.5 Magnetic valve & water outlet
5.5.4 Mounting of fresh water filter
Picture 45: Filter housing
• Place the filter into the machine.
• Mount two new cable ties for the fixation of the filter.
Remarks
Cable tie 200 ordering number 4023260.
• Mount the hose onto the fast connector of the filter.
• Close fresh water tank according to chapter MOUNTING OF
FRESH WATER TANK ASSEMBLY.
