TC Electronic SYSTEM 6000 MKII Algorithm Manual

14
vss™-4
Lo Color
Range:-50to50
LoColoradjustmentoftheEarlyReflections
Hi Color
Range:-50to50
HiColoradjustmentoftheEarlyReflections
Early Start
Range: 0 to 100%
AdjustingtheStarttimeisanefficientwayofgettingrid
of the first reflections that normally color the source the
most.ByadjustingtheStarttime,thefirstreflectionsare
discarded but the timing of the later reflections remains
unchanged.Thereforethisadjustmentistypicallymore
acoustically precise and useful than a normal Predelay
control.
The parameter range limit will be less than 100%
iftheEarlyStopparameterissettoanythingother
than 0%.
Early Stop
Range: 0 to 100%
TheEarlyStopparametercanreducethelaterreflections
intheEarlyReflectionspattern.Whenusinglargelocation
types this can be a useful parameter to smooth the overall
perception of the room.
The parameter range limit will be less than 100%
iftheEarlyStartparameterissettoanythingother
than 0%.
Levels
Instead of a mix-parameter controlling the wet/dry signal
balance, three individual levels are available. Overall Input
and Output levels are placed at the Setup page.
Reverb Level
Range: Off to 0dB
AdjusttheleveloftheDiffuseFieldreflections.
Early Level
Range: Off to 0dB
AdjusttheleveloftheEarlyReflectionsfromthetwo
sources.
Dry Level
Range: Off to 0dB
Attenuates the Dry signal level on the Output side thus
leavingtheReverbandEarlyLevelunaffected.Offequals
a“kill-dry”setting.
Setup
Location Type
Location Type
SelectbetweendifferentLocations.BoththeEarly
Reflection-andDiffuseField-typesarechangedwhen
switching Location to give the optimal starting point for
furtheradjustments.
Positions
Source 1 - Source 2
Range:R30º,R15º,R7º,C0º,L7º,L15º,L30º
Sets the location of the two Input sources. Depending
on the Location Type the number of locations can vary.
Typically a small room has less positions than a large
location. Source 1 is Left Input and Source 2 is Right Input.
Levels
In Level
Range: Off to 0dB
Controls the entire algorithm Input level.
Out Level
Range: Off to 0dB
Controls the entire algorithm Output level
