TC Electronic SYSTEM 6000 MKII Algorithm Manual

25
vss™ 5.1 - sOurCE
Positions
Listening Position
Insomelargelocationsit’spossibletochangethelisteners
position. In the smaller locations there is one listening
position available.
Source 1 to 4 positioning
In the selected location it is possible to position the four
Input sources individually. Different numbers of positions
are available, depending on the location type and Output
format.
Sources page
This page contains individual parameters for each of the
four sources.
Source 1-4
Various parameters are available for each of the 4 source
positions. Press Source 1-4 to select which set of source
parametersyouwishtoadjust.
Source 1-4 Early Reflections
Lo Color
Range:+/-50
AdjuststhelowfrequencyspectrumfortheselectedSource.
Hi Color
Range:+/-50
AdjuststhehighfrequencyspectrumfortheselectedSource.
Early Start
Range: 0 to 100%
SetsthestartingpointoftheinitialtapsintheEarly
Reflection pattern (The shortest taps).
The parameter range limit will be less than 100%
iftheEarlyStopparameterissettoanythingother
than 0%.
Early Stop
Range: 100 to 0%
RemovestapsintheEarlyReflectionpatternfromtheend
of the pattern.
The parameter range limit will be less than 100%
iftheEarlyStartparameterissettoanythingother
than 0%.
Reverb Position
EnablestoemphasizeorchangetheSourcepositionorigin
in the Reverb part of the algorithm.
Source 1-4 Levels
ER Level
Range: -100 to 0dB
AdjuststheleveloftheEarlyReflectionforthesource.
Reverb Level
Range: -100 to 0dB
Adjuststhelevelofthesourcecontributiontothefive
Reverb Tails.
Dry Level
Range: -100 to 0dB
AdjuststhelevelofDrysignalfromthesource.
In Level
Range: -100 to 0dB
AdjuststheoverallInputlevelfromthesource.
Reverb page
At the Reverb page you access Color and Decay
parameters for the five reverb diffuse fields.
Reverb Colors
Lo Color
Range:+/-50
Adjuststhespectralbalanceinthelowendfrequenciesof
the Reverb. All five diffuse fields respond to this parameter.
Mid Color
Range:+/-50
Adjuststhespectralbalanceinthemid-rangefrequencies
of the Reverb. All five diffuse fields respond to this
parameter.
