- 116 -
Fig. 8.5 Locations of Rollers (2- to 3.0-ton Trucks)
LIFT CYLINDER
OUTER
CHANNEL
INNER
CHANNEL
SIDE ROLLER
CARRIAGE
SLIPPER
END ROLLER
END ROLLER
END ROLLER
END ROLLER
Upper section
Lower section
8. LOAD HANDLING SYSTEM
