- 125 -
9. ELECTRIC SYSTEM
Headlights
Capacity 48 V - 40 W
Front combination lights
Capacity
Side marker lights 48 V - 10 W
Turn signal lights 48 V - 25 W
Rear combination lights
Capacity
Tail/brake lights 48 V - 10 W/25 W
Turn signal lights 48 V - 23 W
Back-up lights 48 V - 10 W
9.1 SYSTEM DESCRIPTION
The electric system components, excluding the speed controller and its related components, get
their electricity from a high-capacity battery installed in the truck. They include head lights and
front and rear combination lights, which are turned on and off via the relay unit.
9. ELECTRIC SYSTEM
