TCM FB30-8 - Pump Motor

- 17 -
2.1.2 PUMP MOTOR
The pump motor is located on the left side frame and is used to drive the main pump.
Its rotation is controlled by the load handling inverter built in the speed controller only when the
lift lever is operated. Except that, the pump motor is used for starting or stopping the rotation of
the main pump.
ポンプモータ
A
A
メインポンプ
Fig. 2.6 Pump Motor
MAIN PUMP
PUMP MOTOR
View looking from
A
2. MOTORS
