- 18 -
回転センサ
締付トルク
10～12N・m
B
B
Ｕ相端子 Ｖ相端子 Ｗ相端子
Fig. 2.7 Pump Motor
Tightening torque:
10 to 12 N-m
[100 to 120 kgf-cm]
{7.4 to 8.9 lbf-ft]
U PHASE
TERMINAL
V PHASE
TERMINAL
W PHASE
TERMINAL
View looking from
A
View looking from
B
ROTATION SENSOR
THERMO-SENSOR
CONNECTOR
2. MOTORS
