TCM FB30-8 - Page 156

- 130 -
(2) Turn signal switch
The turn signal switch is incorporated into the right lever of the turn signal and light switch
assembly. When the lever is moved forward or backward, the left or right turn signal lights ash
accordingly.
When the lever is moved forward, terminals
TB
and
TL
are connected to each other, causing
the turn signals in the left front and rear combination light assemblies to ash; and when the lever
is moved backward, terminals
TB
and
TR
are connected to each other, and the turn signals in the
right front and rear combination light assemblies ash.
(25W) (25W) (25W) (25W)
N
R
L
TB
TR TL
F-9 F-8 F-25 F-24 F-10 F-22 F-13 F-26
(RR) (RL)
B+
F4
F5
LW 132
G 105
L 131
GR 106
G 105
RG 102
RG 102
B 2
RW12
RW12
R 5
10A
10A
ࡈࡠࡦ࠻
ࠦࡦࡆࡀ࡯࡚ࠪࡦ
࡜ࡦࡊᏀ
ࡈࡠࡦ࠻
ࠦࡦࡆࡀ࡯࡚ࠪࡦ
࡜ࡦࡊฝ
࡝ࡗ
ࠦࡦࡆࡀ࡯࡚ࠪࡦ
࡜ࡦࡊฝ
࡝ࡗ
ࠦࡦࡆࡀ࡯࡚ࠪࡦ
࡜ࡦࡊᏀ
࡝࡟࡯࡙࠾࠶࠻
࠲࡯ࡦࠪࠣ࠽࡞ࠬࠗ࠶࠴
ࡃ࠶࠹࡝
࠲࡯ࡦࠪࠣ࠽࡞࡜ࡦࡊ ࠲࡯ࡦࠪࠣ࠽࡞࡜ࡦࡊ ࠲࡯ࡦࠪࠣ࠽࡞࡜ࡦࡊ ࠲࡯ࡦࠪࠣ࠽࡞࡜ࡦࡊ
Fig. 9.5 Turn Signal Circuit
RELAY UNIT
TURN SIGNAL SWITCH
KEY SWITCH
TURN SIGNAL LIGHT
TURN SIGNAL LIGHT
TURN SIGNAL LIGHT
TURN SIGNAL LIGHT
BATTERY
FRONT
COMBINATION
LIGHT (LEFT)
FRONT
COMBINATION
LIGHT (RIGHT)
REAR
COMBINATION
LIGHT (LEFT)
REAR
COMBINATION
LIGHT (RIGHT)
9. ELECTRIC SYSTEM
