TCM FB30-8 - SPECIFICATIONS; SPECIFICATIONS (1)

SPECIFICATIONS (1)
Truck model
Item
FB10-8 FB15-8 FB18-8 FB20-8
Performance
Max. load kg [lbs] 1000 [2000] 1500 [3000] 1750 [3500] 2000 [4000]
Load center mm [in.] 500 [24]
← ← ←
Max. lifting height mm [in.] 3000 [118.1]
← ← ←
Tilting angle
Fwd
°
6
← ← ←
Bwd
°
12
← ← ←
Free lift A mm [in.] 155 [6.1]
← ←
110 [4.3]
Mast tilting time (Fwd - Bwd) s 2.0 - 1.4
← ←
2.7 - 2.0
Fork lifting speed
Loaded mm/s [fpm] 390 [76.8] 350 [68.9] 330 [65.0] 290 [57.1]
Unloaded mm/s [fpm] 580 [114.2]
← ←
510 [100.4]
Travel speed
Loaded km/h [mph] 14 [8.7]
← ← ←
Unloaded km/h [mph] 16 [9.9]
← ← ←
Gradeability
(Starting on an uphill when loaded) 1/7
← ← ←
Min. turning radius
(Outermost part of truck) EPS: B mm [in.] 1700 [66.9]
←
1790 [70.5] 1950 [76.8]
Orbitrol type: 1800 [70.9]
←
1890 [74.4] 2070 [81.5]
Min. intersecting aisle C mm [in.] 1690 [66.5]
←
1730 [68.1] 1895 [79.6]
Dimensions mm [in.]
Overall length (includ. fork) D 2875 [113.2]
←
2975 [117.1] 3315 [130.5]
Overall width E 1070 [42.1]
← ←
1150 [45.3]
Overall height (Overhead guard) F 2080 [81.9]
← ←
2125 [83.7]
EXN: 2140 [84.3]
← ←
2185 [86.0]
Overall extended height 4030 [158.7]
← ← ←
Wheel base G 1250 [49.2]
←
1350 [53.2] 1400 [55.1]
Tread
Front wheels H 910 [35.8]
← ←
955 [37.6]
Rear wheels J 900 [35.4]
← ←
950 [37.4]
Fork overhang K 375 [14.8]
← ←
435 [17.1]
Rear overhang L 330 [13.0]
← ←
410 [16.1]
Fork size
(Length L x Width M x Thickness N)
920x100x35
[36.2x3.9x1.4]
← ←
1070x122x40
[42.1x4.8x1.6]
Fork spacing Q
200 - 920
[7.9 - 36.2]
← ←
245 -1020
[9.6 - 40.2]
Minimum under clearance
90 [3.5]
(Rear axle)
← ←
100 [3.9]
(Rear axle)
Tow pin height 390 [15.4]
← ←
440 [17.3]
Weight
Service Weight with std. batteries kg [lbf] 2680 [5908] 2710 [5976] 3030 [6680] 3500 [7716]
The values in the Performance section are given for trucks operating in the Super mode.
