- 40 -
高さ： 97mm（FB10～25）
110mm（FB30～35）
Fig. 5.2 Brake Pedal
BRAKE SWITCH
RESERVE TANK
MASTER CYLINDER
BRAKE SWITCH OPERATION DISTANCE: 5 – 10 mm [1.97 – 3.94 in.]
Height: 97 mm [3.8 in.] (FB10 - 25)
110 mm [4.3 in.] (FB30 - 35)
View looking from
A
5. BRAKE SYSTEM
