Installaon Procedure — Addive Injecon Pump
There are two selecons for managing Addive Injecon Pumps; External and Piston.
EXTERNAL: The External funcon for Addive Injecon is to
provide an posive output signal during the enre delivery pro-
cess to manage an external addive injecon pump. The
source power voltage is what you will receive from the terminal
named PMP. START.
NOTE: If using Throle Control 1, this will deacvate the External addive injecon
pump.
Addive Meter: A single or dual channel addive ow meter
can be wired into the ADD. INJ. PULSER terminal to inde-
pendently measure addive volume during a ow rate. Cali-
brate Addive Meter within following PISTON addive selec-
on, then switch back to External.
BLACK
RED
BLACK
RED
GND — GND
+5V — VIN
TAHA2 — CHA
TAHB2 — CHB
PISTON: The Piston funcon for Addive
Injecon is to provide calibrated posive output
signals during the enre delivery process to actuate
an external addive injecon pump. The source
power voltage is what you will receive from the ter-
minal named ADD. INJECTOR VALVE.
Addive Meter: A single or dual channel addive
ow meter can be wired into the ADD. INJ. PULSER
terminal to independently measure addive volume
during a ow rate.
GND — GND
+5V — VIN
TAHA2 — CHA
TAHB2 — CHB
NOTE: Addive Injecon Pump and Valve terminals will not operate in Weights & Measures mode. Calibraon for the PISTON
addive injecon pump and ow meter are required to be performed outside W&M Sengs, then changed within W&M
