TCS 3000 - Remote Display Installation

33
TCS 3000 Installation
www.tcsmeters.com
Total Control Systems
Installaon Procedure:
See Red Lion, Omega or Tekinno serial slave display manuals for RS-485 programming and wiring Instrucons.
WARNING: The external remote display requires an External Power Source, do not pull power from the TCS 3000 regis-
ter.
Installaon Procedure — Remote Display
External Power Source
