TCS 3000 Installation

Installaon Procedure — TCS 682 Series Meter

Before beginning the installaon of the TCS 3000 register, unpack the enre contents of the packaging in a safe loca-

on where you will not misplace any of the parts. Lay out the parts as they would be installed. This will ensure that

you have all the correct parts for the installaon. Verifying all the necessary parts were included in the shipment in

advance will reduce downme and avoid any wasted preparaon work.

Item Qty TCS 300871

Metric

TCS 300971

NPT

Phillips Pan 6 TCS300137 TCS300137

Spring Washer 6 TCS300138 TCS300138

Terminal Cover 1 TCS300164 TCS300164

7.5 AMP Fuse 1 TCS300192 TCS300192

Fuse Holder 1 TCS300193 TCS300193

Cable Gland 4 TCS300249 TCS300133

USB Fem/Mini Male Cable 1 TCS300705 TCS300705

Resistor 1K OHM 2 TCS300753 TCS300753

1/4—28 X 3/4 Zinc Bolt 2 TCS68004 TCS68004

1/4—28 X 3/4 Drilled Bolt 2 TCS68004D TCS68004D

Drive Coupling, 682 1 TCS600420 TCS600420

3/64 X 1 Coer Pin 1 TCS790091 TCS790091

Installaon Procedure:

1. Remove and put aside the four mounng bolts and any mounng adaptor. Remove the exisng mechanical regis-

ter or electronic register, if applicable. Use a box or container to set old equipment and parts in.

2. Using the sha specic to your installaon, slide the Drive Sha Coupling on the Pulser Sha and align the holes.

Once the holes are aligned insert the Coer Pin and bend the pin ends back around the Drive Coupling.

3. Slide the Drive Coupling onto the Meter Drive Sha.

4. Rotate the TCS 3000 register unl the display is facing in the desired direcon and check to see that the meter

holes align with the holes at the base of the TCS 3000 register.

5. Secure the bolts.

682 Drive Coupling

Coer Pin

TCS 3000 Installation Manual
