TCS 3000 Installation Manual

23
TCS 3000 Installation
www.tcsmeters.com
Total Control Systems
Item Qty TCS 300815
NPT
Cable Gland, 1/2 NPT UL 1 TCS 300133
O-Ring, 1/2 NPT Gland 1 TCS 300255
4 Wire 100 Ω Temperature Probe 1 TCS 300701
Temperature Probe Jacket 1 TCS 300702
Capplug T6X 1 TCS 300719
Copper Anseize 2 Gram 1 TCS 300749
Thermowell 1/2” Stainless Steel 1 TCS 740400
Thermowell 3/8” Stainless Steel 1 TCS 740405
Nylon Spacer Lock 1 TCS 740302
Drilled 3/8’ SS Washer 1 TCS 740303
Item Qty TCS 300811
NPT
Cable Gland, 1/2 NPT UL 1 TCS 300133
O-Ring, 1/2 NPT Gland 1 TCS 300255
4 Wire 100 Ω Temperature Probe 1 TCS 300701
Temperature Probe Jacket 1 TCS 300702
Capplug T6X 1 TCS 300719
Copper Anseize 2 Gram 1 TCS 300749
Thermowell 1/2” NPT Aluminum 1 TCS 740300
Thermowell 3/8” NPT Aluminum 1 TCS 740305
Nylon Spacer Lock 1 TCS 740302
Drilled 3/8’ SS Washer 1 TCS 740303
TCS 3000 RTD Probe/SS Thermowell Kit
TCS 3000 RTD Probe/Aluminum Thermowell Kit
Installaon Procedure — Temperature Probe Kit
