34
www.tcsmeters.com
Total Control Systems
TCS 3000 Installation
Installaon Procedure — 1 Channel Communicaon Installaon
Installaon Procedure:
1. Remove the six Screws holding the Wiring Shield to the M8 x 27 Standos.
2. Remove the two top M8 x 27 MM Standos and replace with two M4 x 14 Standos
3. With two M4 x 14 Standos, mount the Single Channel Communicaon Board over the two top (short) M4 x 11
Standos.
4. Install the Wiring Shield with six Screws.
5. Replace USB cable adapter into wiring shield for safe keeping.
COMMUNICATION BOARD
M4 X 14 STANDOFF
SCREWS
WIRING SHIELD
M4 X 11 STANDOFF
To Next Page
