TCS 3000 Installation

www.tcsmeters.com

Total Control Systems

TCS 3000 Soware Update Kit (TCS 300882)

Item Qty TCS P/N

USB FEM/Mini Male Cable 1 TCS 300787

TCS 3000 USB 1 TCS 300795

USB Thumb Drive with

communication LED

Mini USB Port

Male Mini USB to

Female USB

FIGURE 1

Installaon Procedure — Soware Update

Installaon Procedure:

1. Load new soware upgrade to a USB thumb drive (Minimum 8G, Formaed FAT 32).

NOTE: The new soware upgrade should be the ONLY le on the drive.

2. Open the TCS 3000 register. On the front cover of the register, there are 2 mini-USB connecons. Using a factory

supplied USB cable, aach the thumb drive to the USB port closest to the inside of the register. This port is the

highest on the circuit board of the two. See Figure 1.

3. Plug the USB cable into the USB port, and then insert the USB thumb drive into the mang cable (see Figure 1).

4. Under Advanced Funcons, locate System Update and press ENTER.

5. The screen will display System Update, press MODE to connue with the update.

6. If the thumb drive is not recognized or there is a faulty cable, the display will respond with NO UPDATE DATA error

message.

7. Once the le is recognized, you will be prompted to remove the media. Remove the USB and the register will re-

boot and begin the update process. This should take approximately 3 minutes.
