Name Description Min Max Default UM Scale
DCBUS_REF_MAIN_LOST P98 - Voltage reference value in Support 1 220.0
1200.
0
600 V 10
TDE_PAR_KEY P99 - Access key to TDE parameters 0 19999 0 1
RES_PAR_KEY_VAL
P100 - Value of access key to reserved
parameters
0 19999 95
1
DRV_F_PWM P101 - PWM frequency 1000 16000 5000 Hz 1
PRC_DEAD_TIME_CMP P102 - Dead time compensation 0.0 100.0 22.0
‰
PRC_MOT_V_MAX
32.76
PRC_DRV_I_MAX P103 - Drive limit current 0.0 800.0 200 % DRV_I_NOM 40.96
T_RAD P104 - Radiator time constant 10.0 360.0 80 s 10
KP_DCBUS P105 - Corrective factor for Bus voltage 80.0 200.0 100 % 10
DCBUS_MIN P106 - Minimum voltage of DC Bus 220.0
1200.
0
400 V 10
DCBUS_MAX P107 - Maximum voltage of DC Bus 350.0
1200.
0
800 V 10
DCBUS_BRAKE_ON P108 - Bus voltage threshold for brake ON 350.0
1200.
0
770 V 10
DCBUS_BRAKE_OFF P109 - Bus voltage threshold for brake OFF 350.0
1200.
0
760 V 10
OFFSET_AO1 P110 - Offset A/D 1 -100.0 100.0 0 % 327.67
OFFSET_AO2 P111 - Offset A/D 2 -100.0 100.0 0 % 327.67
DRV_I_PEAK P113 - Maximum drive current 0.0
3000.
0
0 A 10
PRC_I_TEST_CONN
P114 - Current in connection tests for UVW,
Poles and reading Rs
0.0 100.0 100 % DRV_I_NOM 327.67
KP_MOT_THERM_PRB
P115 - Multiplication factor for motor
PTC/NTC/PT100 analog reference value
0.00
200.0
0
100
163.84
T_JUNC P116 - Junction time constant 0.1 10.0 3.5 s 10
KP_DRV_THERM_PRB
P117 - Multiplication factor for radiator
PTC/NTC analog reference value
0.00
200.0
0
100
163.84
DRV_TEMP_MAX
P118 - Max. temperature permitted by
radiator PTC/NTC
0.0 150.0 90 °C 10
DRV_START_TEMP_MAX
P119 - Max. temperature permitted by
radiator PTC/NTC for start-up
0.0 150.0 75 °C 10
DRV_DO_TEMP_THR
P120 - Radiator temperature threshold for
logic output o.15
0.0 150.0 80 °C 10
TEST3-4_ACC_TIME P121 - Test 3 and 4 acceleration time 0.01
199.9
9
6.8 s 100
MOD_INDEX_MAX P122 - Max. modulation index 0.500 0.995 0.98 1000
DCBUS_REF P123 - Smart brake voltage cut-in level 300.0
1200.
0
750 V 10
PRC_ENC_OUT_LOOP
P124 - Simulated encoder Kv gain
multiplication coeff.
0.0 100.0 100 % 327.67
PRC_V_REF_DCBUS P125 - Voltage reference function of DC bus 0.0 100.0 96.0 % 327.67
PRC_I_REG_KP_COEFF
P126 - KpI Corrective coeff. estimated Kp
for current loops
0.0 200.0 100 % 40.96
PRC_V_REG_KP_COEFF
P127 - KpV Corrective coeff. estimated Kp
for voltage loops
0.0 200.0 100 % 40.96
MOT_V0
P128 - Voltage motor at nominal speed with
no load
0.0 100.0 100.0 % MOT_V_NOM 327.67
PRC_I_TEST_DELTA_VLS P129 - Test current to establish VLS 0.0 100.0 30.0 % 327.67
TEST_SPD_T_MAX P130 - Torque during start-up test 0.0 100.0 100 % MOT_T_NOM 40.96
K_FLX45 P131 - Magnetic characteristic point 1 0.0 120.0 90.2 % 40.96
TEST_SPD_MAX P132 - Speed during start-up test -100.00
100.0
0
100 % MOT_SPD_MAX 163.84
K_FLX55 P133 - Magnetic characteristic point 2 0.0 120.0 90.5 % 40.96
TEST_SPD_SPACE_MAX
P134 - Maximum revolutions during start-up
test
0.00
3000.
0
100 revolutions 10
K_FLX65 P135 - Magnetic characteristic point 3 0.0 120.0 91.1 % 40.96
PRC_MOT_FRICTION P136 - Friction torque 0.0 100.0 0 % MOT_T_MOM 40.96
K_FLX75 P137 - Magnetic characteristic point 4 0.0 120.0 91.8 % 40.96
KP_REG_THERM_PRB
P138 - Multiplication factor for regulation
card thermal probe
0.00
200.0
0
100
163.84
K_FLX82 P139 - Magnetic characteristic point 5 0.0 120.0 92.7 % 40.96
BRAKE_R P140 - Braking resistance 1 1000 82 Ohm 1
K_FLX88 P141 - Magnetic characteristic point 6 0.0 120.0 94.2 % 40.96
BRAKE_R_MAX_EN
P142 - Braking resistance Maximum
adiabatic Energy
0.0 500.0 4.5 KJoule 10
K_FLX93 P143 - Magnetic characteristic point 7 0.0 120.0 95.8 % 40.96
BRAKE_R_MAX_EN_TIME
P144 - Time measure of Braking resistance
adiabatic Energy
0 30000 2000 ms 1
