User’s manual
4.1.2.3 15 (OF HEX) FORCE MULTIPLE COILS
This function enables to set the value of digital inputs via serial line. As previously said, the digital
inputs via serial line are all parallel to the related digital inputs via terminal board except the RUN
enable ( where the two inputs are in series )
Starting address Max data number Digital inputs
Starting address(hex) Max data number Description
0360 32 Digital inputs
4.1.2.4 16 (10 HEX) PRESET MULTIPLE REGISTERS
This function allows to set the value of the parameters, connections and to enable the alarms even if
the corresponding keys are opened.
To correctly set these data it is required the right address ( that you can find in the following table)
and it is necessary to consider the internal data representation, referring to the specific descriptions
of the core. The application area’s meaning depends on the present application (see specific
documentation):
starting address Max data number Description
0000 200 Parameters table
00C8 100 Connections table
012C 100 Applications data table
0203 1 Alarms enabling
0360 1 Digital input
If it is written a value not included in the range, the value will be ignored and the previous one will
remain valid.
4.1.2.5 EXCEPTION RESPONSES
The following exception codes in the answer are managed:
Code Name Description
01 Not managed function The drive doesn’t manage this Modbus function
02 Wrong data address The address is not valid
03 Wrong data value The data number required is too big
