5.2.20- CONFIGURAZIONE DI
DEFAULT I/O
Riferirsi al manuale utente della serie OPDE per ulte-
riori informazioni sulla configurazione degli I/O.
INGRESSO / INPUT DEFAULT CONNESSIONE / CONNECTION
L.I.1
Reset allarmi.
Alarms Reset.
C01 = 8
L.I.2
Consenso esterno.
External consent.
C02 = 2
L.I.3
Abilitazione riferimento analogico A.I.1 a 14 bit.
Enable 14 bit analog reference A.I.1
C03 = 3
L.I.4
Azionamento in marcia (stadio di potenza abilitato).
Drive ON (power stage enabled).
C04 = 0
L.I.5
Abilitazione riferimento analogico A.I.2 a 14 bit.
Enable 14 bit analog reference A.I.2.
C05 = 4
L.I.6
CW/CCW C06 = 12
L.I.7
Abilitazione jog di velocità.
Enable speed jog.
C07 = 5
L.I.8
Abilitazione rampe lineari.
Enable linear ramps.
C08 = 22
USCITA / OUTPUT
DEFAULT
CONNESSIONE / CONNECTION
L.O.1
Azionamento in marcia (stadio di potenza abilitato).
Drive switched on (power stage enabled).
C10 = 3
L.O.2
Azionamento pronto.
Drive ready.
C11 = 0
L.O.3
Completata la rampa sul riferimento di velocità.
End of ramp on the speed reference.
C12 = 6
L.O.4
Velocità superiore alla minima.
Speed higher than the minimum one.
C13 = 2
USCITA / OUTPUT
DEFAULT
CONNESSIONE / CONNECTION
VOUTA
Modulo della corrente erogata dal convertitore.
Module of the current supplied by converter.
C15 = 11
VOUTB
Frequenza di lavoro o velocità motore.
Working frequency or motor speed.
C16 = 4
TAB. 19 (Configurazione di default I/O / Default I/O configuration)
5.2.20- DEFAULT I/O CONFIGURA-
TION
For additional information on I/O configurations pls.
refer to the OPDE series User Manual.
