7.3.3 Operational Group (Status Register) Structure
Operational condition status register group holds a snapshot of the actual status state of the power
supply at a present time. Power supply status might quickly change its condition before the
controlling PC detects it. Events can be stored in the Event register if the Enable register allows it.
Refer to General Status Register Commands (section 5.10.9) set. Table 7-8 describes bit
configuration of the operational group register.
Bit Number
Decimal Value
Bit Symbol
Description
0
1
CV
Constant Voltage operation mode
1
2
CC
Constant Current operation mode
2
4
NFLT
No Fault
3
8
-
-
4
16
AST
Auto Start Enabled
5
32
FBE
Foldback Enabled
6
64
-
-
7
128
LOC
Local / Remote communication mode
8
256
UVP
Under Voltage Protection enabled
9
512
ILC enable
Interlock control Enabled
10
1024
ENA enable
Enable control Enabled
11
2048
CFB
CC operation mode Foldback enabled
12
4096
EVR
External Voltage Reference Programming
13
8192
ECR
External Current Reference Programming
14
16384
CPE
Constant Power Enabled
15
32768
CP
Constant Power operation mode
Table 7-8: Bit Configuration of Operational Condition Register
7.3.4 Command Error (“Cxx”)
Power supply responds with a command error if it receives an unrecognized command or a
command, which is recognized, but cannot be executed. Command error response format is
‘Cnn<CR>‘ where ‘nn’ is ‘01’ to ‘05’. The following execution error commands are available:
C01 Illegal command or query
C02 Missing parameter
C03 Illegal parameter
C04 Checksum error
C05 Setting out of range
