SUPPLY CONFIGURATIONS
Local Control
Supply may be controlled from the Front Panel even if LAN is
LAN Remote Control
Supply may be controlled and monitored through LAN
RS232, RS485, USB
LAN interface is disabled if the standard RS-232, RS-485, USB or
Optional communications are active
Analog Control
LAN may monitor supply while analog control is used
INDICATORS
IP and MAC Address
View addresses on Front Panel or communication
Multi-drop Address
View RS-485 address on Front Panel
Link/Activity LED
Indicates that connection is active. network packets are being
Speed LED
Indicates the speed
LAN Status LED
Red/Green, indicates power supply has valid IP connection
Blink Identify
Find the Master Supply by remotely blinking Front Panel and Rear
SECURITY
Web Page Password
Can set password to prevent unauthorized or accidental changes
to LAN settings or power supply output settings
Single Client Only
Set to prevent multiple programs from taking control
Block UDP Sockets
Single client will block attacks through UDP sockets
Disable VXI-11
Stop power supply detection
Disable Ping Server
Stop power supply detection
Disable mDNS
Stop power supply detection
5.7.2.2 LAN Command Speed
The following communication speeds are typical values only. In addition to the variability in the
LAN interface, there are timing variations within the controller and the network routing.
The following speed specifications are subject to change without notice.
•
VISA Drivers, Sockets, Web.
•
Typical Command or query speeds:
All commands and queries have a response time in the range of 5~30ms, depending on the
command and the amount of parameters sent/received. Refer to the notes for specific commands
which require longer process/transmission time.
