5.14.11 TRIGger Subsystem
NOTE:
The Trigger subsystem must be enabled from the Initiate subsystem. If disabled, commands from
the trigger subsystem will not affect Power Supply output.
TRIGger[:IMMediate]
Function If Trigger is enabled (by INITiate command), TRIG generates an
immediate trigger signal.
TRIGger:DELay <NRf+>
Function Sets a time delay between trigger events of a specified trigger source to the
start of any corresponding trigger action over the Power Supply output.
Parameters
0.000…10.000s Step:0.001 Sec.
Unit
S
Query
TRIGger:DELay?; TRIGger:DELay? MIN; TRIGger:DELay? MAX
Return
<NR2>
NOTE:
The TRIGger command overrides TRIGger:DELay. It activates trigger immediately.
TRIGger:SOURce <DSC>
Function Selects a trigger source:
• BUS - *TRG or TRIG commands and Front Panel.
•
EXT – Rear Panel Trigger IN pin (J1-22).
Parameters
BUS|EXT
Query
TRIGger:SOURce?
Return
<DSC> BUS|EXT
