11
No.
Control/Indicator
Description
6 Current Display 4-digit 16-segment Current display.
Normally displays the output current.
In Preview mode, the display indicates the program setting of
the output current.
In menu navigation, the display indicates the selected
parameter.
7 Indicators Bar Refer to Figure 2–2 and Table 2-2: Front Panel Display and
Indicators for description of the front panel Indicators bar.
8 Current Encoder and
Button
Encoder: A high-resolution detent rotary Encoder adjusting
the output current and navigating menu.
Button: An auxiliary function to accept the current-setting
value, select menu level, and set parameter value.
9
BACK Button
Return one step back in menu navigation mode.
10 PROG Button / Indicator Activates the Program / Sequencer menu.
The Program menu provides Sequencer function control,
Trigger function control, and loads a sequence stored inside
the power supply memory.
Green LED lights when Program menu is active. If Program
menu is active, press PROG button to exit to the main
display. *
11 SYST / Lock Front Panel
Button / Indicator
Activates the System menu.
The System menu provides output sensing point selection
(Local / Remote sense), Interlock function control, Enable
function control, Power Supply OK signal control,
SAVE/RECALL power supply configuration, Programmable
Signals control, Preload function control, Display brightness &
dimming function control, and reset power supply settings.
Green LED lights when the System menu is active.
If the System menu is active, press the SYST button to exit
to the main menu.
Lock / Unlock Front Panel buttons by pressing the SYST
button, followed by current encoder press. *
