TDK-Lambda G10-500 - Page 26

18
No.
Connection
Description
Section
8 VPGM Input for remote (analog) voltage/resistance programming of
the Output Voltage.
9
NOT USED
10 ENA_IN Enable / Disable the power supply output by dry-contact (short /
open) or voltage source. Selectable signal polarity.
11
COM
COMMON. Return for all signals.
12
COM
COMMON. Return for all signals.
13
COM
COMMON. Return for all signals.
14
COM
COMMON. Return for all signals.
15
NOT USED
16
NOT USED
17
COM
COMMON. Return for all signals.
18
COM
COMMON. Return for all signals.
19 ILC Enable / Disable the power supply output by dry-contact (short /
open) or voltage source.
20
Programmed Signal 2
General Purpose Open Drain Port 2.
21
Programmed Signal 1
General Purpose Open Drain Port 1
22 Trigger In Power supply trigger input for sequencer operations. Positive
edge triggered, pulse width: min. 10usec.
23
Trigger Out
Trigger output, positive edge, pulse width: min. 100usec.
24
NOT USED
25
I_MON
Output for monitoring the power supply output Current.
26
V_MON
Output for monitoring the power supply output Voltage.
Table 2-4: J1 Connector Terminals and Functions
