1.3 ACCESSORIES
Included Accessories 1.3.1
The following accessories are delivered with the power supply:
1.3.1.1 Serial Link Cable
Serial link cable for linking power supplies by RS-485 communication (GEN/RJ45).
Cable description: 0.5m length, shielded, RJ-45 type plugs, eight (8) contacts (P/N: 15-507-201)
1.3.1.2 Hardware (delivered with power supply)
 Strain Relief for AC Cord
 Output terminal shield
 DB25 Programming Plug kit (AMP P/N: 749809-9)
 Connector plug kit, (Phoenix Contact: Plug: IMC 1, 5/7-ST-3,81, Header: IMC 1,5/7-G-3,81)
Optional Communication Cables (See Section 7.5) 1.3.2
 RS-232 Cables to connect GEN to Serial Port on PC
GEN-to-PC (DB9) GEN 232/9 P/N: 15-507-203
GEN-to-PC (DB25) GEN 232/25 P/N: 15-507-204
 RS-485 Cable to connect GEN to Serial Port on PC
GEN-to-PC (DB9) GEN/485-9 P/N: 15-507-202
AC Cables 1.3.3
AC cables are not provided with the power supply. Refer to Table 1-2 for recommended AC input cables
(customer supplied). Add a non-locking plug approved by the national safety standards of the country of usage.
AC Input Range
AC Input Cable
190-240VAC, Single-Phase
Min. 3x12AWG (2 wire plus safety ground), stranded
copper, 300V, 60°C minimum, rated for 25A. 3m max.
length, outer diameter: 9~11mm.
190-240VAC, Three-Phase
Min. 4x14AWG (3 wire plus safety ground), stranded
copper, 600V, 60°C minimum, rated for 15A. 3m max.
length, outer diameter: 9~11mm.
Table 1-2: Recommended AC Input Cable
