Command Set Categories 7.7.2
The Genesys™ 2400W Power Supply Series command set is divided into four categories as follows:
1. Initialization Control
2. ID Control
3. Output Control
4. Status Control
Initialization Control Commands 7.7.3
#
Command
Description
1
ADR n
ADR is followed by address, which can be 0 to 30, and is used to access the power
supply.
2
CLS
Clear status. Sets FEVE and SEVE registers to zero (refer to Section 7-8).
3
RST
Reset command. Brings the power supply to a safe and known state:
Output voltage: zero Remote/Local Mode: non-lockout remote
Output current: zero, Auto-ReStart mode: OFF
Output ON/OFF: OFF OVP setting: maximum
FOLDback ON/OFF: OFF UVL setting: zero
The conditional registers (FLT and STAT) are updated while other registers are not
changed.
4
RMT
Sets the power supply to local or remote mode:
1. RMT 0 or RMT LOC, sets the power supply into Local mode.
2. RMT 1 or RMT REM, sets the unit into Remote mode.
3. RMT 2 or RMT LLO, sets the unit into Local Lockout mode (Latched Remote mode).
5
RMT?
Returns to the Remote mode setting:
1. “LOC”: The unit is in Local mode.
2. “REM”: The unit is in Remote mode.
3. “LLO”: The unit is in Local Lockout (Latched Remote) mode.
6
MDAV?
Returns MD MODE OPTION Status. “1” indicates installed, and “0” indicates not installed.
7
\
Repeat last command. If \<CR> is received, the power supply will repeat the last
command.
ID Control Commands 7.7.4
#
Command
Description
1
IDN?
Returns the power supply model identification as an ASCII string: LAMBDA, GENX-Y
2
REV?
Returns the software version as an ASCII string.
3
SN?
Returns the unit serial number. Up to 12 characters.
4
DATE?
Returns date of last test. Date format: yyyy/mm/dd
Output Control Commands 7.7.5
#
Command
Description
1
PV n
Sets the Output voltage value in Volts. The range of Output voltage value is described in
Table 7-3. The maximum number of characters is 12. See the following examples for PV
n format: PV 12, PV 012, PV 12.0, PV 012.00, etc…
2
PV?
Reads the Output voltage setting. Returns the string “n” where “n” is the exact string sent
in the PV n command. When in Local mode, returns the PREView (front panel) settings
in a 5 digit string.
3
MV?
Reads the actual Output voltage. Returns a 5 digit string.
Example: 60V supply sends 01.150, 15.012, 50.000, etc…
4
PC n
(See Note 1)
Sets the Output current value in Amperes. The range of Output current value is described
in Table 7-4. The maximum number of characters is 12. See the following examples for
PC n format: PC 10, PC 10.0, PC 010.00, etc…
5
PC?
Reads the Output current setting. Returns the string “n” where “n” is the exact string sent
in the PC n command. When in Local mode, returns the PREView (front panel) settings
in a 5 digit string.
6
MC?
(See Note 2)
Reads the actual Output current. Returns a 5 digit string.
Example: 200A supply sends 000.50, 110.12, 200.00, etc…
