7.7.5 Output Control Commands (continued)
#
Command
Description
7
DVC?
Display Voltage and Current data. Data will be returned as a string of ASCII characters. A
comma will separate the different fields. The fields, in order, are: Measured Voltage,
Programmed Voltage, Measured Current, Programmed Current, Over-Voltage Set Point
and Under-Voltage Set Point.
Example: 5.9999,6.0000,010.02,010.00,7.500,0.000
8
OUT n
Turns the output to ON or OFF. Recover from Safe-Start, OVP or FLD fault.
OUT 1 (or OUT ON): Turn Output ON; OUT 0 (or OUT OFF): Turn Output OFF
9
OUT?
Returns the Output ON/OFF status string.
ON: Output ON. OFF: Output OFF.
10
FLD n
Sets the FOLDback protection to ON or OFF.
FLD 1 (or FOLD ON) - Arms the FOLDback protection
FLD 0 (or FOLD OFF) - Cancels the FOLDback protection.
When the Foldback protection has been activated, the FLD 1 command will release the
protection and re-arm it, while the FLD 0 command will cancel the protection.
11
FLD?
Returns the FOLDback protection status string:
ON: FOLDback is armed. OFF: FOLDback is cancelled.
12
FBD nn
Add (nn x 0.1) seconds to the FOLDback Delay. This delay is in addition to the standard
delay. The range of nn is 0 to 255. The value is stored in EPROM memory at AC Input
power down and recovered at AC Input power up.
13
FBD ?
Returns the value of the added FOLDback Delay.
14
FBDRST
Resets the added FOLDback Delay to zero.
15
OVP n
Sets the OVP level. The OVP setting range is given in Table 7-5. The number of
characters after OVP is up to 12. The minimum setting level is approximately 105% of the
Output voltage setting, or the value in Table 7-6, whichever is higher. The maximum
setting level is shown in Table 5-1. Attempting to program the OVP below this level will
result in an execution error response (“E04”) and the OVP setting stays unchanged.
16
OVP?
Returns the setting “n” where “n” is the exact string from the “OVP n” command. When in
Local mode, returns the last setting from the front panel in a 4 digit string.
17
OVM
Sets OVP level to the maximum level. Refer to Table 7-5.
18
UVL n
Sets the Under Voltage Limit level. Value of “n” may be equal to the PV setting, but
returns “E06” if higher. Refer to Table 7-6 for UVL programming range.
19
UVL?
Returns the setting “n” where “n” is the exact string from the “UVL n” command. When in
Local mode, returns the last setting from the front panel in a 4 digit string.
20
AST n
Sets the Auto-Restart mode to ON or OFF.
AST 1 (or AST ON): Auto-Restart ON.
AST 0 (or AST OFF): Auto restart OFF.
21
AST?
Returns the string Auto-Restart mode status.
22
SAV
Saves “Present Settings”. The “Present Settings” are the same as power-down “Last
Settings”. These settings are erased when the power supply AC Input power is switched
OFF and the new “Last Settings” are saved.
23
RCL
Recalls “Last Settings”. Settings are from the last AC Input power-down or from the last
“SAV” command.
24
MODE?
Returns the power supply operation mode. When the power supply Output is ON (OUT 1)
it will return “CV” or “CC”. When the power supply Output is OFF (OUT 0) it will return
“OFF”.
25
MS?
Returns the unit Master/Slave setting. Master: n = 1, 2, 3, or 4 Slave: n = 0
