CHAPTER 2 SPECIFICATIONS
2.1 OUTPUT RATING
MODEL
GEN
8-300
10-240
16-150
20-120
30-80
40-60
60-40
80-30
100-24
150-16
300-8
600-4
1.Rated Output voltage, (*1)
V
8
10
16
20
30
40
60
80
100
150
300
600
2.Rated Output current, (*2)
A
300
240
150
120
80
60
40
30
24
16
8
4
3.Rated Output power
W
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2.2 AUXILIARY OUTPUTS
1. +15V Output, (*14)
---
+15V ± 5% 0.2A max load, Ripple & Noise: 100mVp-p. Referenced internally to the negative output (-Vout) potential
2. +5V Output, (*14)
---
+5V ± 5%, 0.2A max load, Ripple & Noise: 100mVp-p. Referenced internally to IF_COM potential
2.3 INPUT CHARACTERISTICS
V
8
10
16
20
30
40
60
80
100
150
300
600
1.Input voltage/frequency, (*3)
---
Single-Phase, 2 wire + Ground, 200VAC models: 170VAC~265 VAC, 47~63Hz
Three-Phase, 3 wire + Ground, 200VAC models: 170VAC~265 VAC, 47~63 Hz
2.Maximum input
current at 100%
load
1-Phase 230VAC
models
---
17.3
17.3
16.8
16.7
16.7
16.6
16.6
16.6
16.6
16.3
16.3
16.3
3-Phase 208VAC
models
10.5
10.5
10.2
10.1
10.0
10.0
9.9
9.9
9.9
9.8
9.8
9.8
3. Power Factor (typical)
---
Single-Phase models: 0.99 @ 230VAC, rated Output power; Three-Phase models:0.94 @ 200VAC, rated Output power.
4. Efficiency (typical), (*4)
%
84
84
86
87
87
88
88
88
88
88
88
88
5. Inrush current, (*5)
---
Less than 50A
2.4 CONSTANT-VOLTAGE MODE
V
8
10
16
20
30
40
60
80
100
150
300
600
1. Max. Line regulation, (*6)
---
0.01% of rated Output voltage + 2mV
2. Max. Load regulation, (*7)
---
0.015% of rated Output voltage + 5mV
3. Ripple and Noise (p-p, 20MHz), (*8)
mV
50
50
50
50
55
55
60
60
70
90
150
240
4. Ripple (rms, 5Hz~1MHz)
mV
6
6
6
6
6
6
6
7
10
20
45
60
5. Temperature coefficient
ppm/°C
+/- 50ppm/°C from rated Output voltage, following 30 minute warm-up
6. Temperature stability
%
+/- 0.01% of rated Output voltage over 8 hr interval following 30 minute warm-up. Constant line, load & temperature
7. Warm-up drift
---
Less than +/- 0.05% of rated Output voltage + 2mV over 30 minutes, following Output power on
8. Remote sense compensation/wire
V
2
2
2
2
5
5
5
5
5
5
5
5
9. Up-Prog. response time, 0~Vomax, (*9)
ms
15
15
15
15
15
20
30
40
40
60
80
100
10. Down-Prog
response time
Full load, (*9)
ms
10
10
20
20
20
20
30
50
50
80
100
100
No load, (*10)
500
500
500
500
600
700
1100
1200
1500
2500
3000
3000
11. Transient response time
ms
Time for Output voltage to recover within 0.5% of its rated Output for a load change 10~90% of rated output current. Output voltage
set-point: 10~100%, local sense
Less than 1ms for models up to and including 100V. Less than 2ms for models above 100V
12. Hold-up time (typical)
ms
10ms, rated Output power
2.5 CONSTANT-CURRENT MODE
V
8
10
16
20
30
40
60
80
100
150
300
600
1. Max. Line regulation, (*6)
---
0.01% of rated Output current +2mA
2. Max Load regulation, (*11)
---
0.02% of rated Output current +5mA
3. Load regulation thermal drift
%
Less than 0.05% of rated Output current over 30 minutes following load change
4. Ripple (rms,, 5Hz~1MHz), (*12)
mA
700
500
400
250
150
90
60
40
30
12
10
5
5. Temperature coefficient
ppm/°C
+/- 70PPM/°C from rated output current, following 30 minutes warm-up
6. Temperature stability
%
+/- 0.01% of rated Iout over 8 hrs. interval following 30 minutes warm-up. Constant line, load & temperature
7. Warm-up drift
---
8~16V models: Less than +/- 0.2% of rated Output current over 30 minutes, following power on
20V~600V models: Less than +/- 0.1% of rated Output current over 30 minutes, following power on
2.6 ANALOG PROGRAMMING AND MONITORING
1. Vout voltage programming
---
0~100%, 0~5V or 0~10V, user-selectable. Accuracy and linearity: +/-0.5% of rated Vout
2. Iout voltage programming, (*13)
---
0~100%, 0~5V or 0~10V, user-selectable. Accuracy and linearity: +/-1% of rated Iout
3. Vout resistor programming
---
0~100%, 0~5/10Kohm full scale, user-selectable. Accuracy and linearity: +/-1% of rated Vout
4. Iout resistor programming, (*13)
---
0~100%, 0~5/10Kohm full scale, user-selectable. Accuracy and linearity: +/-1.5% of rated Iout
5. On/off control (SO)
---
By electrical Voltage: 0~0.6V/2~15V or dry contact, user selectable logic
6. Output current monitor, (*13)
---
0~5 or 0~10V, user-selectable. Accuracy: +/-1%
7. Output voltage monitor
---
0~5 or 0~10V, user-selectable. Accuracy: +/-1%
8. Power supply OK signal (PS_OK)
---
4~5V = OK, 0V = Fail. 500 ohm series resistance
9. Parallel operation
---
Possible, up to 4 units in Master/Slave mode with two wire current balance connection
10. Series operation
---
Possible (with external diodes), up to 2 units. 600VDC maximum from Chassis ground
11. CV/CC indicator
---
Open collector. CC mode = On, CV mode = Off. Maximum voltage: 30V, Maximum sink current: 10mA
12. Enable/Disable
---
Dry contact. Open = Off, Short = On. Maximum voltage at Enable /Disable IN: 6V
13. Local/Remote analog control
---
By electrical signal or Open/Short: 0.0/0.6V or short = Remote, 2~15V or open = Local
14. Local/Remote analog indicator
---
Open collector, Local = Open, Remote = On. Maximum voltage:30V, Maximum sink current: 10mA
2.7 PROGRAMMING AND READBACK (RS-232/485, Optional LAN, IEEE, USB Interface)
V
8
10
16
20
30
40
60
80
100
150
300
600
1.Vout programming accuracy,
(*15)
---
0.05% of rated Output voltage
2.Iout programming accuracy,
(*13)
---
0.1% of actual Output current + 0.2% of rated Output current
3.Vout programming resolution
---
0.002% of rated Output voltage
4.Iout programming resolution
---
0.002% of rated Output current
5.Vout readback accuracy
---
0.05% of rated Output voltage
6.Iout readback accuracy, (*13)
---
0.3% of rated Output current
7.Vout readback resolution
% of rated
Output voltage
0.002%
0.011%
0.007%
0.006%
0.004%
0.003%
0.002%
0.002%
0.011%
0.007%
0.004%
0.002%
8.Iout readback resolution
% of rated
Output current
0.004%
0.005%
0.007%
0.009%
0.002%
0.002%
0.003%
0.004%
0.005%
0.007%
0.002%
0.003%
