83-517-000 Rev. A
NOTES:
*1: Minimum voltage is guaranteed to maximum 0.2% of the rated Output voltage.
*2: Minimum current is guaranteed to maximum 0.4% of the rated Output current.
*3: For cases where conformance to various safety standards (UL, IEC etc.) is required, to be described as
190~240VAC (50/60Hz).
*4: A 200VAC input voltage, Ta=25C with rated Output power.
*5: Not including EMI filter inrush current, less than 0.2ms.
*6: At 170~265VAC, constant load.
*7: From no-load to full-load, constant input voltage. Measured at the sensing point in Remote Sense.
*8: For 8V~300V models: measured with JEITA RC-9131A (1:1) probe.
For 600V model: measured with 10:1 probe.
*9: From 10%-to-90% or 90%-to-10% of rated Output voltage, with rated, resistive load.
*10: From 90%-to-10% of rated Output voltage.
*11: For load voltage change, equal to the unit Output voltage rating, constant input voltage.
*12: For 8V~16V models the ripple is measured at 2V to rated Output voltage and rated Output current. For
other models, the ripple is measured at 10~100% of rated Output voltage and rated Output current.
*13: The constant current programming readback and monitoring accuracy does not include the warm-up and
load regulation thermal drift.
*14: Measured with JEITA RC-9131A(1:1) probe.
*15: Measured at the sensing point.
2.14 SUPPLEMENTAL CHARACTERISTICS
The supplemental characteristics give typical but non-warranted performance characteristics. The supplemental
characteristics are useful in assessing applications for the power supply. Several kinds of supplemental
characteristics are listed below.
1. Evaluation Data: Typical performance of the power supply.
2. Reliability Data: Reliability Performance of the power supply.
3. EN61000 Data: Performance of the power supply under EN61000 test conditions.
4. EMI Data: Typical EMI (conducted and radiated) performance of the power supply.
