TDK-Lambda GENESYS GEN 2400W Series - Page 47

83-517-000 Rev. A
37
Table 4-1: Front Panel Controls and Indicators (continued)
Number
Control/Indicator
Description
Section
7
OUT button
Main function: Output ON/OFF control. Press OUT to set the
output ON or OFF. Press OUT to turn On the output after OVP
or FOLD alarm events have occurred.
Auxiliary function: Selects between “Safe-Start” and “Auto-
Restart” modes. Press and hold OUT button to toggle between
“Safe-Start” and “Auto-Restart”. The VOLTAGE display will
cycle between “SAF” and “AU7”. Releasing the OUT button
while one of the modes is displayed, selects that mode.
5.6
5.11
8
OUT indicator
Green LED, illuminates when the DC output is enabled.
9
REM/LOC button
Main function: Go to Local mode. Press REM/LOC to put the
unit into Local mode (REM/LOC button is disabled at Local
Lockout mode).
Auxiliary function: Address and Baud Rate setting. Press and
hold REM/LOC for 3 seconds to set the unit Address with the
VOLTAGE encoder and the Baud Rate with the CURRENT
encoder.
7.2.5
7.2.2
7.2.4
10
REM/LOC indicator
Green LED, lights when the unit is in Remote mode.
11
FOLD button
FOLDback protection control.
- Press FOLD to set Foldback protection to ON.
- To release FOLDback alarm event, press OUT to enable the
output and re-arm the FOLDback protection.
- Press FOLD again to cancel the FOLDback protection.
5.5
12
FOLD indicator
Green LED, lights when FOLDback protection is ON.
13
OVP/UVL button
Over Voltage Protection and Under Voltage Limit setting.
- Press once to set OVP using VOLTAGE encoder (the current
display shows “OUP”)
- Press again to set the UVL using VOLTAGE encoder (the
current display shows “UUL”).
5.3
5.4
14
PREV/ button
Main function: Press PREV to display the Output voltage and
Output current limit setting. For 5 seconds the display will show
the PREView settings and then it will return to show the actual
Output voltage and Output current.
Auxiliary function: Front Panel Lock. Press and hold PREV
button to toggle between “Locked Front Panel” and “Unlocked
Front Panel”. The display will cycle between “LFP” and “UFP”.
Releasing the PREView button while one of the modes is
displayed selects that mode.
5.17
15
PREV indicator
Green LED, lights when the PREView button is pressed
16
FINE button
Voltage and Current Fine/Coarse adjustment control. Operates
as a toggle switch. In FINE mode, the VOLTAGE and
CURRENT encoders operate with high resolution and in
COARSE mode with lower resolution (approximately 6 turns).
Auxiliary function: Advanced Parallel Operation Mode Setting.
5.15.2
17
FINE indicator
Green LED, lights when the unit is in FINE mode.
18
ALARM indicator
Red LED, blinks in case of fault detection. OVP, OTP.
FOLDback, Enable and AC fail detection will cause the ALARM
LED to blink.
19
AC Power switch
AC ON/OFF control.
