LAN Timeout
If the user is logged in via the web page or by using VISA or TCP sockets, this is the time
duration (in seconds) in which the web pages may be inactive (idle) before the power supply
automatically logs out.
The default is 1800 seconds = 30 minutes.
NOTE
Maximum Timeout setting is limited to 60000 seconds = 1000 minutes.
•
Ping Server
Ping is a network utility that allows the computer to verify communication with the power
supply. This service can be disabled on the Modify panel for security reasons.
•
Auto-Negotiate
Shows the network speed at which the LAN card is allowed to operate. The choices are 100
Mbps, 10 Mbps (for slower networks) or Auto select.
•
VXI-11 Discovery
This is a protocol, which allows the network server to detect which instruments are connected
to the LAN. It may be disabled for security reasons.
•
Auto-MDIX
This service is always enabled in the power supply. The power supply LAN connection will
always detect a patch or cross-over cable automatically.
•
Apply
Click this button to save the new settings. A pop-up box will ask you to close or refresh the
page. ‘admin’ log-in will be logged-out.
•
Close
Click this button to return to the LAN Configure Page shown in section A.
D. LAN ➔ Users Page
This page allows creating password protection for the web pages. There is no password protection
for automation programming with VISA or sockets.
By default, the old password is blank. The new password must contain between 6 and 16
characters. Password is case sensitive.
NOTE
Only a~z, A~Z and 0~9 characters are allowed.
Reset Password
Once a password is applied, it may be changed by using the same screen, but it can only be
removed by performing the LAN Reset function.
