6. LSServer, Scanner Shell and Download
6-70 Operating Manual for the LS Series Scanner No. 30001798 Rev. No. 1.5 2004-11
Move Plate and Filter…
In the Instrument menu, select Move Plate and Filter… and the Movements
dialog box appears.
In the
Movements dialog box, specific In and Out buttons can be used to drive
the plate carrier or filter slides into or out of the LS Series Scanner. Click
OK to
close the dialog box.
For further information refer to the chapter Plate/ Filter on page 6-26 description
in this manual.
Edit Measurement Parameters…
In the Instrument menu, select Edit Measurement Parameters… or on the
toolbar click the
Edit Parameter button or press Ctrl + F5 and the Measurement
Parameter
dialog box appears.
In the
Measurement Parameter dialog box general options like Scan Mode,
Stacker and/or Barcode as well as Geometry Parameters and Scan Settings can
be defined.
For further information refer to the chapter Edit… on page 6-28 in this manual.
Start Measurement
The Start Measurement option is not available in the Instrument menu of the
Scanner Shell software.
Disconnect
In the Instrument menu, select the Disconnect option to disconnect the currently
connected instrument. Another instrument can then be connected.
Note
This option is only available, if an instrument is already connected.
