6. LSServer, Scanner Shell and Download
2004-11 Operating Manual for the LS Series Scanner No. 30001798 Rev. No. 1.5 6-105
Exit
In the File menu, select Exit and the LSDownload software will be exited.
View Menu
Status Bar
In the View menu, select Status Bar to show / hide the LSDownload software
Status Bar.
When the
Status Bar option is selected (√) the LSDownload software Status
Bar
will be shown.
The status bar displays following information:
• Help access: Press
F1 for Help
• Activity of the keyboard toggles: CAP (caps lock), NUM (Numeric block
lock), SCRL (Scroll lock).
When the
Status Bar option is cleared the LSDownload software Status Bar will
be hidden.
Instrument Menu
Connect
This option allows an instrument to be connected.
In the
Instrument menu, select Connect or in the Instrument group box click
Connect Instrument…or press Shift + F5 and the Setup Port dialog box
appears. Select the desired instrument and communication port from the drop-
down lists.
For further information refer to the chapter 6.2 Tecan LS Scanner Interface
description in this manual.
The desired instrument will be connected using the selected communication port.
A message in the
window area of the LSDownload software shows that the
connection is successful or unsuccessful:
Connection Message in report area of LSDownload
Unsuccessful
No instrument connected!
Successful
LS SERIES SCANNER ….
V…
V…
