16
3 ACCESS BY WEBSERVER
You can get access to the Webserver by connecting the device via the GB A Port (RJ-
45) to your PC. Here the IP-address of the device is dependent on the status of the
rotary switch (see CHAPTER 2.2.1)
Or you get access to the Webserver by the 100BASE-T1 Port to the Microcontroller and
the default IP address 192.168.0.49. This port is configured as 100BASE-T1-slave as
default.
1. Please go to the network adapter settings and adjust the IP in the same range of
your CM_100_High, dependent on which port you are connected to.
Note: Please make sure that the Internet Protocol Version 6 (TCP/IPv6) option is
disabled.
2. Enter the IP Address in your standard web browser. For details see CHAPTER 2.2.1
and CHAPTER 4.3.
Note: Firefox is the recommended browser.
3. The following website should appear.
Figure 3-1: Home Screen CM_100_High
