CM 100 High User Manual
6
Features:
6 Link Line 100BASE-T1 (12 Ports)
Configure easily via Webserver
Network Time Synchronization (802.1AS) – allows to synchronize multiple Eth
Combos or any other “Capture Module”
Source Timestamping with 40 ns resolution
Rotary Switch for manual configuration of the device’s IP-Addresses
(Gbit – RJ-45)
Wakeup capable
Robust stainless-steel case
General Information:
Power requirement:
8 to 16 Volt DC (nominal 12 Volt DC)
Power consumption:
5,7 to 7,8 Watt
Size:
167 x 143 x 32 mm
Weight:
1,0 kg
International Protection:
IP 2 0
Operating temperature:
-30°Celsius to 50°Celsius (prototype)
LINKS:
The User can download the latest firmware and documentation for the CM_100_High
here:
https://technica-engineering.de/en/produkt/capture-module-100-high/
