GROUP CYCLE: Service & Maintenance manual rev. 6.4
Page 2.2
2.2 PRODUCT CHARACTERISTICS
Min – max user height
140-240cm / 4,6” – 6,9”
Max user weight
160Kg / 320lbs
Q factor
180mm / 7”
Transmission
Chain
Frame
Aluminium
Dual-sided SPD pedals
STANDARD
Lock system for home environment
OPTIONAL
2.3 MECHANICAL CARACHTERISTICS
Width
595 mm / 23”
Length
1375 mm / 54”
Height
1200 mm / 47”
Weight
60 Kg / 132 lbs
2.3.1 OVERALL DIMENSIONS IN USE
