Technogym GROUP CYCLE - Disassemblin the Secondary Pulley

GROUP CYCLE: Service & Maintenance manual rev. 6.4
Page 6.24
6.11 DISASSEMBLIN THE SECONDARY PULLEY
Figure 6.11-1
Carry out the procedure of disassembly
described in paragraph: 6.10“Disassembling the
belt and flywheel group” up to point (8).
On a work bench:
1. Back off the ring nut (a)
using a socket
wrench for ring nut.
2. Remove the secondary pulley (b).
CAUTION: During the reassembly lock
down the pulley end the ring nut
, using
a torque wrench set for 60Nm.
