GROUP CYCLE: Service & Maintenance manual rev. 6.4
Page 7.3
Figure 7.1-6
CAUTION: To adjust the chain tension
is important to equally act on both sides
of flywheel. The flywheel must be
centred into the fork.
The flywheel must be centred in the
fork;
the "X" dimensions must be the
same in all four positions.
