RUNRACE : Service & Maintenance Manual - rev. 2.0
Page 7.7
To reassemble the new KEYBOARD, with the
display placed on a work bench:
1. Remove the backing film from the adhesive
side.
2. Apply the adhesive part, starting from the left
and working toward the right, being careful
not to bend the KEYBOARD.
3. Plug the connector into the CPU board.
4. Remove the protective film.
5. Reassemble the display.
When reassembling the KEYBOARD,
make sure that none of the keys are bent
or remain pushed in.
The KEYBOARD assembly procedure
can only be carried out once, because
disassembly damages the tracks and
keys.
