RUNRACE : Service & Maintenance Manual - rev. 2.0
Page 7.20
7.16. DISASSEMBLING THE SHOCK ABSORBERS
Figure 7.16-1
Carry out the procedure described in paragraph
7.15. “Disassembling the tread belt and running
track”.
For the new model:
1. On each side of the machine, back off the 2
nuts a using a 13-mm wrench.
2. Pull out the SHOCK ABSORBERS from the
top.
To reassemble the SHOCK ABSORBERS, carry
out the above steps in reverse order.
