RUNRACE : Service & Maintenance Manual - rev. 2.0
Page 2.9
CONNECTORS
• CPU board
Name Type of connector Connection
CN1 AMP MATE-N-LOCK 15-pin F To up-down and inverter interface boards
CN2 AMP MATE-N-LOCK 12-pin F To serial ports
CN3 AMP MODU II 6-pin M To emergency button
CN5 AMP MODU II 2-pin M To back up battery
CN6 AMP MODU II 8-pin M To TGS interface
K7 AMP MODU II 4-pin M To cardio receiver
• Power supply
Name Type of connector Connection
CN1 PANDUIT 6-pin To mains electricity supply
CN2 PANDUIT 8-pin To inverter interface board
• Inverter interface board
Name Type of connector Connection
CN1 AMP MATE-N-LOCK 6-pin F To inverter
CN2 AMP MATE-N-LOCK 12-pin F To CPU board
CN4 AMP MOD I 4-pin M To power supply
• Up-down board
Name Type of connector Connection
CN1 AMP MOD II 4-pin M To photocell
CN2 AMP MATE-N-LOCK 4-pin F To CPU board
CN3 AMP MATE-N-LOCK 6-pin F To up-down motor and microswitches
CN4 AMP MATE-N-LOCK 2-pin F To mains electricity supply
CN5 Sauro 2-pin To transformer
CN6 Sauro 2-pin To rectifier bridge
• Patch cables
Name Type of connector Connection
CN1 AMP MATE-N-LOCK 15-pin M To CPU board
CN2 AMP MATE-N-LOCK 15-poli F To up-down and inverter interface boards
CN3 AMP MATE-N-LOCK 12-poli M To CPU board
CN4 AMP MATE-N-LOCK 12-poli F To serial ports
