Technogym Skillmill GO - STRUCTURE FOR ENTERING COMMANDS; 6.2.1 READING FIRMWARE VERSIONS

Select the available COM
and press CONNECT
Select the Baud rate 19200
Command input eld
Make sure that it is agged
as indicated
Figure 10
6.2 STRUCTURE FOR ENTERING COMMANDS
The structure of the command/message is: @COMANDO [ARG1] [ARG2]#
Character Required Description
@ YES Message start marker.
COMMAND YES
Command. The acceptable commands are described in the
following sections.
ARG1 NO First Topic of the command (if required by the command)
ARG2 NO Second Topic of the command (if required by the command)
#
(hash)
YES Message end marker
Table 9
6.2.1 READING FIRMWARE VERSIONS
6.2.1.1 (CPU) FIRMWARE VERSION
Command Notes
Command @FWVER# Prints CPU rmware version.
Table 10
Skillmill
Technical Service Guide - Rev. 2.2
Page 38
e-mail: support@technogym.com
